Easily deploy sustainable 10G bandwith

The XGX‑2410B is the ideal XGS‑PON ONT solution delivering faster speeds for deployment scenarios with FiberTray.

The XGX-2410B

WAN port
0 x SFP+
LAN port
0 x 10GE
LAN ports
0 x 1GE
Recycled plastics
0 %

Endless possibilities with the XG Series

  • Modular building possibilities (CATV and SFP)

    The XG is designed and developed to ensure maximum flexibility, resulting in the XG Series’ modular building design. Different features, such as fiber termination, CATV, SFP, or RJ45, can be added as needed for your deployment while still maintaining the same form factor. In other words, create the XG device that fits your deployment scenario.

  • Easy to install FiberTray

    The XG Series can be deployed in a stand-alone form or with a FiberTray. The FiberTray allows installers to manage excessive fiber and install the XG wherever easily. In addition, the FiberTray is backward compatible with all previous XG products. The robust design of the FiberTray is specifically designed so that your created XG fits perfectly, allowing it to be installed in every environment.

  • Backwards compatible

    The XG is specifically designed to fit XG FiberTray anywhere and anytime. Therefore, the XG always fits on previously installed FiberTrays. As an operator, you do not need to worry about what to do with already installed FiberTrays. Thanks to its design, simply slide the (new) XG on the existing FiberTray, and the end user can continue to enjoy their connection.

  • Flexible in every way

    The XG is designed to fit in multiple deployment scenarios for 1GE Point-to-Point, 10GE Point-to-Point, and XGS-PON. It has a flexible choice of WAN port (SFP or RJ45), 4 LAN ports, and an extra LAN port when using SFP; it can be deployed stand-alone or with a FiberTray combination and even with CATV if needed.

  • Always fits

    Thanks to its flexibility and modular building possibilities, the XG is a suitable and scalable network termination device that operators need when deploying in different scenarios.

  • Experience the ultimate in flexibility, performance, and ease of deployment with the XG Series

Our XGX-2410B meets the EU requirements of the Radio Equipment Directive (RED)
Our XGX-2410B meets the EU requirements of the Radio Equipment Directive (RED)

General specifications

  • Dimensions (HxWxD) 28x110x140 mm
  • Weight 296 gr
  • Operating temperature 0 - 40°C
  • Storage temperature -20 - 55°C
  • Operating humidity 5% ~ 95%
  • Storage humidity 5% ~ 95%

Power consumption (EU-CoC-BBE)

  • Idle mode TBD
  • On mode TBD

Interface specifications

  • WAN interface 1x 10GE SFP+
  • LAN interface 3x 1GE
  • LAN interface 1x 10GE

Regulatory compliance

  • Electromagnetic Compatibility Directive 2014/30/EU
  • Low Voltage Directive 2014/35/EU
  • RoHS Directive 2011/65/EU and Delegated Directive (EU) 2015/863
  • REACH EC Regulation 1907/2006
  • EU-CoC-BBE
  • Other ITU-T K.21 standard compliancy
Our XGX-2410B meets the EU requirements of the Radio Equipment Directive (RED)

XGX-2410B downloads

Here, you can access all the relevant downloads for the XGX-2410B. AIf you need additional information or have any questions, please don’t hesitate to contact a Genexis sales representative.
